High-performance amateur HF/50 MHz linear amplifier with 1 kW full-duty output at 180–264 V AC, SO2R, 2×6 automatic antenna selector, built-in tuner, 4.3-inch touchscreen and LAN remote control.
Expected delivery: 04-10-2026
ICOM IC-PW2 is a 1 kW HF/50 MHz linear amplifier for high-performance amateur stations and contest operation. It uses 65 V LDMOS devices and a high-efficiency power supply, delivering 1 kW at 180–264 V AC or 500 W at 90–132 V AC.
The IC-PW2 integrates SO2R capability with two transceiver inputs and six antenna outputs, a built-in automatic antenna tuner and a detachable 4.3-inch colour touchscreen controller. A LAN interface and optional RS-PW2 support advanced remote control.
The company imports, installs and supports radio-communication and internal company-security systems. Integra-A is a distributor of radio-communication equipment and accessories, including hand-held, mobile and fixed-mount transceivers, digital and analog radios, marine and air-band radios, license-free radios, amateur radios, receivers, cables, power-supply units, antennas, microphones, mounts and specialist security equipment.
| Weight | 22 kg |
|---|---|
| Portability | |
| Manufacturer | |
| Type of user |
– Bands: 1.9 / 3.5 / 7 / 10 / 14 / 18 / 21 / 24 / 28 / 50 MHz amateur bands
– Output power: 1 kW at 180–264 V AC; 500 W at 90–132 V AC
– Maximum driving power: 100 W
– Power requirements: 90–132 V AC or 180–264 V AC
– Power consumption: 2000 VA at 100 V AC / 3000 VA at 200 V AC
– RF inputs: 2 x PL-239, 50 Ω
– RF outputs: 6 x PL-239, 50 Ω
– ATU matching range: 16.7–150 Ω, HF–50 MHz
– Tuning time: 2–3 s average; 15 s maximum
– Controller display: 4.3-inch colour touchscreen
– Dimensions (W x H x D): 425 x 149 x 445 mm
– Weight: approximately 22 kg
– Operating temperature: -10°C to +40°C
– 3 m ACC cable
– 3 m control cable
– 3 m coaxial cable
– 3 m mini plug cable
– controller bracket
– front plate for separated RF unit
