1.2 GHz D-STAR DV/DD/FM repeater with integrated controller, 10 W/1 W output, 128 kbps DD mode, FM/DV mixed mode, Ethernet, SD card and optional LTE connectivity.
Expected delivery: 04-10-2026
ICOM ID-RP1200VD is a 1.2 GHz D-STAR digital repeater with an integrated controller, capable of standalone operation and combination with other modules in the ID-RP family. The European version covers 1240–1300 MHz.
In addition to D-STAR DV, the ID-RP1200VD supports DD mode for 128 kbps digital data and analogue FM operation. The optional UX-262 LTE unit provides mobile-network Internet connectivity, while multiple repeater modules can share a gateway.
The company imports, installs and supports radio-communication and internal company-security systems. Integra-A is a distributor of radio-communication equipment and accessories, including hand-held, mobile and fixed-mount transceivers, digital and analog radios, marine and air-band radios, license-free radios, amateur radios, receivers, cables, power-supply units, antennas, microphones, mounts and specialist security equipment.
| Weight | 6 kg |
|---|---|
| Type of user | |
| Portability | |
| Manufacturer |
– European TX/RX range: 1240–1300 MHz
– Modes: D-STAR DV, DD and analogue FM
– DV data rate: 4.8 kbps
– DD data rate: 128 kbps
– Output power: 10 W / 1 W
– Receiver architecture: Down Conversion IF Sampling
– Power requirement: 13.8 V DC ±15%
– TX current: <5.0 A High / <3.0 A Low
- RX current: <1.8 A at maximum audio
- Audio output: >2.0 W
– Dimensions (W x H x D): 482 x 88 x 275 mm
– Weight: approximately 6 kg
– Operating temperature: -10°C to +50°C
– Form factor: 19-inch rack, 2U
– 3 m DC power cable
– 0.6 m Ethernet cable
– 1 m USB cable
– fuses
– rubber stands
– Allen wrench
