Professional 9 kHz–3.7 GHz wideband communications receiver for analogue and digital signals, with TETRA, DMR, NXDN, D-STAR, dPMR, P25 and other modes, 2000 memories, FFT/Cyber Search and TETRA GSSI group filtering fitted as standard.
Expected delivery: 04-10-2026
AOR AR5700D is a high-end professional communications receiver for commercial, institutional and specialist monitoring applications. Its 9 kHz to 3.7 GHz coverage and digital signal processing support a very broad range of analogue and digital radio systems.
The AR5700D supports TETRA direct and traffic-channel reception, DMR, NXDN, D-STAR, dPMR, APCO P25 Phase 1, YAESU C4FM, ALINCO and D-CR. TETRA GSSI group filtering is fitted as standard, while SD-card audio recording, PC control and current SDR# support expand its monitoring workflow.
The company imports, installs and supports radio-communication and internal company-security systems. Integra-A is a distributor of radio-communication equipment and accessories.
| Weight | 5 kg |
|---|---|
| Portability | FIXED MOUNT |
| Manufacturer | AOR |
– Official name: AR5700D Digital Communications Receiver
– Frequency range: 9 kHz–3.7 GHz
– Tuning steps: 1 Hz–999.999 kHz
– Analogue modes: FM, FM Stereo, AM, synchronous AM, USB, LSB, CW, analogue I/Q, FM video
– Digital modes: D-STAR, YAESU C4FM, ALINCO EJ47, D-CR, NXDN 6.25 kHz, P25 Phase 1, dPMR Tier 1, DMR Tier 1/2, TETRA direct/traffic channel
– Encrypted digital signals: not supported
– TETRA GSSI group filtering: fitted as standard
– Memory: 2000 channels / 40 banks
– Typical scan speed: approximately 100 channels/steps per second
– Frequency stability: 0.1 ppm; up to 0.01 ppm with optional GPS unit
– Audio output: >1.5 W into 8 Ω
– Power: DC 10.7–16 V, 2.0 A at 12 V
– Dimensions: approximately 220 x 97 x 304 mm
– Weight: approximately 5 kg
– Operating temperature: 0°C to +50°C
– AC power adapter
– SD card
– operating manual
– PC control software with licence dongle
– 2 USB cables
