HAND-HELD AMATEUR TRANSCEIVER YAESU FT-70DE

Dual-band digital (C4FM) / analog hand-held transceiver. Rugged construction, excellent audio quality and reliable communication.

Description

Dual-band digital (C4FM) / analog hand-held transceiver. Rugged construction, excellent audio quality and reliable communication.

Additional information

Type of user

Portability

Manufacturer

SPECIFICATIONS

– Frequency range: 137-174, 420-470 MHz Tx/Rx, 108-579.995 MHz Rx
– Number of channels: 1105
– Channel steps: 5/6.25/8.33/10/12.5/15/20/25/50/100 kHz
– Output power: 0.5/2/5W
– Operating temperature range: -20 to +60 C
– IP54
– Backlit LCD and DTMF keypad
– CTCSS/DCS tones
– AMS (Automatic mode select)
– Digital Group ID
– Password
– Multi-color LED Mode/Status indicator
– Dimensions (H x W x D): 98 x 60 x 33 mm

SUPPLIED WITH

– Antenna – Battery pack SBR-24Li (Li-Ion 7.4V 1800 mAh) – Adapter SAD-11C – Belt clip – USB cable
