MOBILE AMATEUR TRANSCEIVER YAESU FTM-510DE ASP

Description

MOBILE AMATEUR TRANSCEIVER YAESU FTM-510DE ASP

YAESU FTM-510DE ASP is a high-end dual-band digital C4FM and analog FM mobile transceiver. It develops the FTM-500 platform with enhanced Super-DX, ASP, PMG and MAG functions.

ASP digitally processes analog audio and reduces noise in weak signals. The dual AESS system uses a speaker in the control head and another in the main unit to provide a total audio output of 9 W.

Main advantages

• 55 W VHF and 50 W UHF output power
• Super-DX and ASP for improved weak-signal reception
• enhanced PMG and MAG functions for monitoring and grouping channels
• AESS sound system with a total audio output of 9 W
• built-in GPS with APRS and WIRES-X support

Integra-A Ltd. has been successful on the Bulgarian market since 1993.

The company imports, installs and supports radio-communication and internal company-security systems. Integra-A is a distributor of radio-communication equipment and accessories, including hand-held, mobile and fixed-mount transceivers, digital and analog radios, marine and air-band radios, license-free radios, amateur radios, receivers, cables, power-supply units, antennas, microphones, mounts and specialist security equipment.

Additional information

SPECIFICATIONS

– Operating modes: digital C4FM and analog FM
– European transmit frequency range: 144–146 MHz / 430–440 MHz
– Receive frequency range: 108–550 MHz
– Output power: 55 W VHF / 50 W UHF; 25 W; 5 W
– Audio output: 9 W total through AESS
– Power supply: 13.8 V DC
– GPS: 66 channels
– Bluetooth: with optional BU-5 module
– Main-unit dimensions (W x H x D): 139 x 42 x 132 mm
– Control-head dimensions (W x H x D): 156 x 64 x 58.6 mm
– Set weight: approximately 1.4 kg
– Operating temperature: -20°C to +60°C

SUPPLIED WITH

– SSM-85D DTMF microphone
– DC power cable
– mounting bracket
– spare 15 A fuse
– operating manual
