Compact professional receive-only discone antenna covering 700 MHz–6 GHz, with an N-female connector, 50 Ω impedance, robust metal construction and wind resistance up to 40 m/s.
Expected delivery: 04-10-2026
AOR DA6000 is a professionally built compact discone antenna for receive applications across the UHF/L/S/C bands from 700 MHz to 6 GHz. Its structure uses 16 horizontal elements and eight radials mounted on a solid support stub.
The N-female socket is housed within the stub mast for improved weather protection. Because of the high operating frequencies, AOR recommends low-loss coaxial cable; coaxial cable is not supplied.
The company imports, installs and supports radio-communication and internal company-security systems. Integra-A is a distributor of radio-communication equipment and accessories.
| Weight | 0,7 kg |
|---|---|
| Portability | |
| Manufacturer |
– Official name: DA6000 Commercial Grade Discone Antenna
– Frequency range: 700 MHz–6 GHz
– Use: receive only
– Impedance: 50 Ω
– Connector: N-female
– Horizontal elements: 16; top diameter approximately 82 mm
– Radials: 8 x 100 mm; overall outer diameter approximately 133 mm
– Antenna height: approximately 232 mm
– Weight: approximately 700 g
– Wind resistance: 40 m/s
– Stub mast: Ø32 mm x 400 mm
– Supported mast: 25–50 mm
– Coaxial cable: not supplied; low-loss type recommended
– DA6000 antenna
– stub mast with securing bolt
– clamps and mounting hardware
– installation sheet
